QED
Airloc ABS Standard Spade

  Airloc System - Best connection possible - for 6 to 8mm posts

Using the latest Airloc technology, this Airloc ABS Wide Spade is the ideal speaker termination to ensure you get the best from your speaker cables. This means that the contact area is maximised and the connection remains uniformly tight. This spade...

Availability:   In Stock
Delivery time:
€8,00 Incl. VAT (BTW)
Quantity:    In Basket
Attention: You need a special Tool to press these plugs onto your cable. Check the QED Screwlock plug to assemble yourself without use of special tools.

THIS AIRLOC ABS STANDARD SPADE GIVES GREAT PERFORMANCE FOR SPEAKER TERMINATION

Using the latest Airloc technology, this Airloc ABS Wide Spade is the ideal speaker termination to ensure you get the best from your speaker cables. This means that the contact area is maximised and the connection remains uniformly tight.
This spade has a dual opening for connection with speaker terminals up to 6mm and 8mm wide.

24K GOLD PLATED

Plugs are gold plated to eliminate oxidization, ensuring a life-long low resistance connection

SPECS

24k Gold plated
High copper brass body
AirlocTM cold weld system
Fits 6mm and 8mm binding posts
Minimum cable size 0.75mm2
Maximum cable size 5.5mm2
Accepts entire QED cable range
Colour-coded ABS barrels
Available in red and black

What is AIRLOC?

Airloc™ is a form of cold weld system that can be used to permanently attach QED Forté™ banana plugs or spade terminals toour entire range of speaker cables.

One of the mainreasons for choosing a QED speaker cable is the superior d.c. resistancecharacteristics offered by our exclusive use of 99.999% oxygen free copperconductors. It seems a shame then to ruin all this attention to detail byneglecting the most vulnerable area of the speaker cable chain - that of thephysical interface between cable and amplifier or speaker terminals.

Seen under a microscope the surface of a typical copper strand is very rough and so using normal screw type terminals - as found on binding posts or cheap banana plugs - electrical contact is only made in a relatively small number of places. Add to this a layer of oxidation - which is inevitable if copper is exposed to the air for even a short time - and the combined resistance of the cable and its termination can creep back up to levels present in a more inferior cable.

By using a cold weld crimp type termination Airloc™ plugs squash the conductors and plug together to improve contact area and reduce resistance.





As can be seen in the graph below, by the time the full pressure has been applied the resistance of the joint has reached a minimum value.



Now, because all the air has been removed from the joint there will be no oxidisation of the contact surfaces so the low resistance will remain for the lifetime of the cable. During the cold weld process the cable and plug become one solid piece of metal.
