Goldring
Elite
MC 0.5 mV +/- 1 dB @ 1 kHz Gyger S 5.7 g
The Elite is an ultra high-performance low-output moving coil cartridge which incorporates Goldring's most recent design features. These include new magnetic circuitry, an ultra-rigid Pocan® body and a Neodymium magnet.
Availability:
In Stock
Delivery time:
€699,00
Incl. VAT (BTW)
The Elite is an ultra high-performance low-output moving coil cartridge which incorporates Goldring's most recent design features. These include new magnetic circuitry, an ultra-rigid Pocan® body and a Neodymium magnet.
The Elite incorporates a Gyger S line contact stylus, providing maximum groove information retrieval and an outstandingly smooth and extended response. Optimum damping on both channels is achieved by symmetrically winding the low-mass armature. Silver wire is used for the coils, which supplies much higher definition than is found in standard record cartridge construction.
Cartridge system: MC
Output voltage: 0.5 mV +/- 1 dB @ 1 kHz
Channel balance 1kHz: 1 dB max. @ 1 kHz
Channel separation 1kHz: 25 dB min. @ 1 kHz
Frequency response: 20Hz-30kHz +/- 2 dB
Compliance: 18 mm/N
Stylus type: Gyger S
Tracking angle: 20 °
Internal inductance: 2 uH
Recommended load Resistance: 100 Ω
Recommended load capacitance: 100 - 500 pF
Cartridge weight: 5.7 g
Output voltage: 0.5 mV +/- 1 dB @ 1 kHz
Channel balance 1kHz: 1 dB max. @ 1 kHz
Channel separation 1kHz: 25 dB min. @ 1 kHz
Frequency response: 20Hz-30kHz +/- 2 dB
Compliance: 18 mm/N
Stylus type: Gyger S
Tracking angle: 20 °
Internal inductance: 2 uH
Recommended load Resistance: 100 Ω
Recommended load capacitance: 100 - 500 pF
Cartridge weight: 5.7 g
